Computers
The Computers tab displays the list of computers and relevant information such as the assigned Policy, Group, Tags, Operating System, Last Deployment Package, Last Deployed On, and Toolkits, Prerequisites, Server Connection, Pre-install, and Installation status.
Click Detailed View to display each stage of the deployment in the order of the deployment status for easier monitoring.
• Toolkits – WinPE Debug Mode, Remove Specific Appx Packages
 | When an imaging action is initiated, an XML file containing the Imaging action (Apply or Capture Image), Imaging Server name, and FICAgent user password is created in the Windows Temp folder. The Imaging utility parses this file and prepares the machines for the specified imaging action by communicating with the Shared folder on the Imaging Server and copying the boot.wim file to the machine. When the Imaging task fails, detailed logs are created under the Windows Temp folder and copied to Imaging Server Network share under a specific folder. Once the machine RAM boots in the WinPE, it again communicates with the network share folder on the Imaging Server. When performing Apply Image, a shared network folder is required to fetch the actual image (install.wim). When performing Capture Image, a shared network folder is required to copy the captured image onto the shared network folder. During WinPE Mode, ImagingHelper.exe is run from drive X (the RAM Drive). The ImagingHelper.log is also created under drive X and copied to C: under the Windows Temp folder. |
• Prerequisites – Required Conditions, BitLocker Check, User Profile Redirections, Network Check
• Server Connection – Contacting Imaging Server, Calculating Disk Space Requirement, Downloading Agent, Copying Boot Image
• Pre-install – Preparing PE Image, Sysprep is in Progress, About to RAM Boot
• Installation Status – Started Pre-install Environment, Contacting Imaging Server, Preparing Disk, Applying/capturing Image, Installing Device Drivers, Editing Captured Image, Uploading Captured Image, Finalizing
A failed task during the imaging process will be displayed with an orange cell background. Hover over the cell with the failed task to display the tooltip describing the failed action. A warning status will be displayed in orange text. You can choose to Retry, Clear Status, view/download Logs, Override Warning, or Abort.
Click Retry to retry the failed task on the selected computer.
Click Clear Status to clear the failed status on the selected computer.
Click Logs > View Sysprep Errors to view detailed information.
Click Logs > Download Sysprep Logs to download the log files.
Click Override Warning to clear the warning status on the selected computer.
Click Abort to abort the Capture Image task. Aborting the task in the console will not abort the current task on the computer.
 | Use the Abort option only if the Capture Image task has failed on the computer and the status on the console remains in progress or waiting. |
Action Toolbar
Action Toolbar for Computers
To view the Action Toolbar for a computer, click on the computer name.
Actions
• Wake-on-LAN – This option is only available for offline computers. Select whether to Wake Now or Set Up Wake-on-LAN.
 | Wake-on-LAN needs to be enabled in the BIOS. |
> Wake Now – Click to wake up the offline computer through the LMS computer.
> Set Up Wake-on-LAN – Click to designate an LMS computer that will be used to wake up the offline computer.
 | Complete the following steps to install and set up Last Man Standing computers: 1. Click Set Up Wake-on-LAN. 2. Select the computer to be designated as Last Man Standing. 3. Click OK to complete the setup. Last Man Standing computers will need to be online to wake any computers on a subnet. |
• Computer Actions – Click Remote to perform remote actions on the selected computer, Shutdown the computer, or Restart the computer.
Remote actions include:
> Log off User – This option forces users to log off during RDP/VNC remote sessions. Once you have enabled this option, you can select to warn the user before being logged off and set up to a maximum of 5 minutes to allow the user to save their current work. Otherwise, the active user will be logged off and any unsaved work will be lost.
If the computer is online, you have the option to set the schedule for Restart/Shutdown. To configure more options, click Restart or Shutdown and click Options. Refer to Schedule for more information.
> RDP
> VNC
> VNC Setup
.
 | VNC should be installed on the target computer as well as the computer where Deploy console is run. If VNC is not installed on the machine where Deploy console is run, you cannot connect to the targeted computer. Complete the following steps to install and set up VNC on the target computer: 1. Click VNC or VNC Setup. You will see a list of computers without VNC on the network. 2. Select a single computer by clicking on the name of the computer. To select multiple computers, use CTRL+CLICK or SHIFT+CLICK (CMD+CLICK for Mac). To select all computers, click Select All Computers. 3. Click Next. 4. Enter a password then click Setup. This will install VNC on the target computer. When the target computer you are connecting to is active and currently logged on, the user will be prompted to approve the request to connect. When there is no response to the request to connect within 60 seconds, the request is denied. When the target computer is logged on but locked, the request to connect is automatically allowed. 5. Click OK to complete the setup for remote connection. VNC is now set up. |
> View Screen – Click to view the screen(s) of the selected computer. If there are multiple monitors attached to the computer, select to view any monitor (1 or 2) or all monitors. You can also set to refresh the view every X seconds.
• Windows Updates – Click Patch Scan to perform a scan of Windows Updates installed or outstanding on the computer.
• Image Computer – Click Image Computer and select the Deployment Package to image the selected computer.
• Capture Image – Click Capture Image to create an Image of the selected computer. Note that capturing 32-bit image is not supported.
• Tag Computer – Displays the tags assigned to the computer, or assign new tags if desired.
• Change Group – Click to change the Group that the computer is assigned to.
To create a new group, type the name of the new group you wish to create in the Create New Group field and click +.
• Change Policy – Click to change the policy assigned to the computer.
After changing the policy assigned to computers, click
to save your changes.
to save your changes.• Set as Cache Server – Click to set the computer as cache server. This saves internet bandwidth by downloading software updates and Windows Updates and distributing them to computers, removing the need for the computers to perform their own individual downloads.
• Set as Last Man Standing – Click to set the computer as Last Man Standing.
• Delete Computer – This option is only available for offline computers. Click to delete a computer. This option will only delete the computer from the console but not uninstall the Deploy Agent from the computer.
If Deploy Agent is still installed, the computer will report back again when it comes online.
• Remove Agent – Click Remove Agent to remove the Cloud Agent and all services from the target computer. When the Cloud Agent is removed, you will need to re-install it on the computer to see the computer on the console.
You can perform actions for multiple computers by clicking on
beside the computer name in the Action Toolbar, and choosing to display the list of computers by categories: By Computer, By Group, By Tag, By Policy. Select the computers from the drop-down list and click Select Computers, or click Select All Computers to select all the computers. Only online computers will be reflected in the Action Toolbar.
beside the computer name in the Action Toolbar, and choosing to display the list of computers by categories: By Computer, By Group, By Tag, By Policy. Select the computers from the drop-down list and click Select Computers, or click Select All Computers to select all the computers. Only online computers will be reflected in the Action Toolbar.
